Full Threaded Tie Rod

Introduction

Threaded Tie Rod series products are very common connectors in piping systems. Its structure is round bar with different thicknesses by threading at both ends or full length to connect with other connectors (such as turnbuckles, ring lug, ear lug etc.).

Threaded Tie Rod are divided into L1 Threaded Tie Rod, L2 left and right Threaded Tie Rod, and L11 full Threaded Tie Rod. Both ends of the L1 threaded boom are right-threaded, one end of the L2 left-right threaded boom is right-threaded and one end is left-handed, and the entire L11 full-threaded boom is right-threaded. The length of the threaded boom is selected according to the design requirements. Limited by the processing technology, the L11 full-thread boom is suitable for booms of Φ36mm and below. Examples of labeling are: d=20, l=500, and labeling L11.20-500. Threaded Tie Rod have basic roughness in general machining, which can meet common requirements. If it is a non-machined thread, it should not be easy to use. Because its accuracy may not meet the general requirements. Therefore, there are basic requirements in the drawings according to the processing method. The standard of threaded boom is formulated by Northwest Electric Power Design Institute. The company specializes in the production of various national standard pipeline supports and hangers, including the Northwest Electric Power Design Institute's soda and water pipeline supports and hangers design manual, the East China Electric Power Design Institute 1983 edition of the pipeline supports and hangers manual, HG/T21629-1999 Ministry of Chemical Industry standard all products, HG/ T20644-1998 VS type variable force spring supports and hangers, JB/T 8130.1-1999 PHA/PHB/PHC/PHD/PHE/LHA/LHB/LHC/LHE/ZHA/ZHB types of constant force spring supports and hangers, JB/T-8130.2-1999 standard manual TD type variable Spring Support and hanger, D-ZD2010 power plant steam and water pipe support and hanger design manual, smoke and air pulverized coal pipe support and hanger design manual, 03S402 indoor pipe support and hanger , 05R417-1S indoor pipe support and hanger, 95R417 indoor heat pipe support and hanger, 97R412 outdoor heat pipe support.
